H851
To use this vessel model, include the line
         USE_VES H851
in your data file.

Main Particulars: 853 X 206.7 X 49.21 FT
Light Ship Weight: 107058 Kips

Comments:

  • Structural model includes prismatics and plates
  • Compartmentation included
  • Vessel coordinate origin is located at bow,keel centerline
  • Maximum jacket weight 60,000 S. Tons
  • Built Korea 87
  • The buoyancy of the tilt beams is modeled here. To get the correct position, you should set the variable lway_wdth to the width of the launch ways.

Click Here to look at the model data file:

Plan:

Profile:
