Bg12
To use this vessel model, include the line
         USE_VES BGL2
in your data file.

Main Particulars: 499 X 120 X 31 FT
Light Ship Weight: 6698 M-Tons

Comments:

  • Structural model with WBOX and plates included
  • Compartmentation included.
  • Launch barge
  • Skidbeam and typical equipment weight included
  • Maximum jacket weight 16,170 s. tons
  • Built Japan 78

Click Here to look at the model data file:

Plan:

Profile:
