HERCULES
To use this vessel model, include the line
                        USE_VES HERCULES
in your data file.

A 2,000 short ton crane/lay barge. The crane can be positioned with the macro:

   c_pos pangle yangle
The above shows their default (stowed) position. Here, pangle ans yangle are pitch and yaw angles respectively. The pitch angles will nominally be negative.

Comments:

  • The crane is included in the model
  • For use in 3-D Diffraction Analysis
  • Compartmentation included

Click Here to look at the model data file:

Plan:

Profile:
